Product Overview
| Attributes for 1 Phase Input | ||
| Phase | 1ph | |
| Voltage | 200/240 VAC +/-10% | |
| AC Induction | ||
| Max Continuous Current | 1.1 A | |
| Open-Loop Peak Current | 3.3 A | |
| Closed-Loop Peak Current | 6.6 A | |
| Motor Shaft Power | 0.18 kW | |
| Servo | ||
| Max Continuous Current | 1.1 A | |
| Peak Current | 6.6 A | |
| Suitable EMC Filter | 4200-3503 | |
| Dimensions | 233mm x 40mm x 174mm | |
| Also Known As | M751-01200022 M751-01200022A | |
| Attributes for 3 Phase Input | ||
| Phase | 3ph | |
| AC Induction | ||
| Max Continuous Current | 2.2 A | |
| Open-Loop Peak Current | 3.3 A | |
| Closed-Loop Peak Current | 6.6 A | |
| Motor Shaft Power | 0.37 kW 0.5 HP | |
| Servo | ||
| Max Continuous Current | 2.2 A | |
| Peak Current | 6.6 A | |
| Suitable EMC Filter | 4200-8744 | |
| New item in original packaging. RS485, Modbus RTU, comes fitted with option module and bracket as standard |
||
